Велосипед Stevens Avantgarde SX Luxe Disc (2016)

Name: Велосипед Stevens Avantgarde SX Luxe Disc (2016)
Brand: Stevens

В корзине шт Перейти

Нет в наличии

Описание

Если использовать термин "Премиум Поход" всерьез, то это про топовый треккинг велосипед Stevens Avantgarde SX Luxe Disc с прекрасно продуманной, легкой алюминиевой рамой, крепкими и надежными дисковыми тормозами Shimano, стильными компонентами трансмиссии Deore XT и множеством деталей высокого качества, которые отличают велосипеды Stevens от конкурентов.

Вес	14.1kg
Размеры	48, 52, 55, 58, 61cm
Рама	Aluminium 6061 TB
Цвет	Titanium Grey

EQUIPMENT

CHASSIS
Frame		Aluminium 6061 TB
Front fork		SR Suntour NCX-E RL Air 15QR, 63mm, Taper
Headset		STEVENS MTB 1 1/2", ZS44/28.6 \| ZS55/40
Brakes		Shimano BR-T615, 180/160mm CL

DRIVETRAIN
Crankset		Shimano Deore XT FC-T780, 48-36-26T, w/ chainguard
Derailleur r		Shimano Deore XT Shadow RD-M781-SGS
Derailleur f		Shimano Deore XT FD-T781-L3
Chain		Shimano CN-HG95
Cassette		Shimano CS-HG81, 11-32T, 10-speed
Pedals		City Superlite Cartridge
Gear ratio		1.80 - 9.69 m, 3*10

WHEELSET
Hubs		Shutter Precision PL-8X \| Shimano Deore XT FH-M785
Rims		Oxygen SSL-D, 21C
Tires		Continental Contact 2 Extralight 42-622, foldable, Reflex

COCKPIT
Handlebar		Oxygen Scorpo Rise 20mm, 9°, 640mm
Stem		Oxygen Scorpo 31.8mm, 17°
Saddle		Selle Royal Viper Gent
Seatpost		Oxygen Scorpo
Shiftlever		Shimano SLX SL-M670-I
Brakelever		Shimano Deore BL-T615
Lighting		B+M IQ2 Eyc T Senso+ 50 Lux \| Shine Evo
Accessories		Racktime Shine Evo system carrier \| integr. Pletscher stand

DATA
Weight		14.1kg
Sizes		48, 52, 55, 58, 61cm
Color(s)		Titanium Grey
Laden weight		130kg

* Bike incl. rider, clothing and luggage

TEST REPORTS

Trekkingbike Super

01/2015

The STEVENS Avantgarde amalgamates sportiness, lightweight, safe function and sound quality into a sort of Swiss-Army-knife bike.

Radtouren Note 1,8

03/2014

Avantgarde Luxe Lady: This is what lady trekking bike has got to be: A place on the podium for Stevens thanks to its perfect handling, outstanding craftsmanship ad awesome specs..

Bike & Trekking (NL) Gut

03/2011

Great touring bike: The Avantgarde is a meticulously crafted, appealing bike with a beautiful frame. It drives excellently with or without baggage.

GEOMETRY

schematische Skizze eines Fahrrades mit eingezeichneten Geometrie-Messpunkten

Frame height (cm)		48	52	55	58	61	Measuring mode
Seattube length	A1	604	634	654	678	701	nominal
Seattube length	A2	480	520	550	580	610	bottom bracket to top of seattube
Seattube length	A3	415	455	486	516	547	bottom bracket to top of top tube
Top tube length	B	537	549	564	579	591
Top tube horizontal	C	558	574	589	605	617	center headtube to center seatpost/seattube
Headtube angle (°)	D	69	70	70	71	71
Seattube angle (°)	E	73.5	72.5	72.5	72.5	72.5
Wheelbase	F	1068	1069	1085	1090	1097
Chainstay length	G	450	450	450	450	450
Headtube length	H	110	135	155	175	195
Bottom bracket drop	I	65	65	65	65	65	distance of bottom bracket to hub level*
Bottom bracket height	K	283	283	283	283	283	distance to ground*
Fork rake	L	42	42	42	42	42
Slope	M	181	172	160	154	146	top tube level distance front to rear
Wheel radius	N	348	348	348	348	348	incl. tires
Standover height	O	734	767	793	819	846	top of top tube to ground**
Fork build height	P	455	455	455	455	455	incl. lower headset cups*
Front wheel - bottom bracket	Q	626	627	643	648	655
Reach	R	385	383	391	400	405	center bottom bracket to center headtube, horizontal
Stack	S	580	605	624	647	668	center bottom bracket to center headtube, vertical
Stack/Reach (1:x)		1.51	1.58	1.6	1.62	1.65	ratio stack to reach
Seatpost diameter		27.2	27.2	27.2	27.2	27.2
Stem length		90	100	100	110	120	center-center
Stem angle (°)		17	17	17	17	17
Handlebar diameter		31.8	31.8	31.8	31.8	31.8
Assembled spacers		23.2 + 5 + 5 + 10 + 10
Handlebar width		640	640	640	640	640
Cranklength		170	170	175	175	175
		48	52	55	58	61
